UHF RFID Reader Module 860-960MHz High Performance Long Range Industrial IoT Device

The UHF E710 module reader is a high-performance, multi-channel, split-type reader/writer. It offers fast reading speeds and long-distance reading capabilities. Constructed with robust and durable materials, it boasts excellent waterproof performance. It supports direct control via AT commands, making it independent of operating systems or frameworks. It is widely used in applications such as warehouse management and parking lot management.

FAQs:

Does the reader support secondary development?

Yes, the reader supports secondary development.

What is its communication interface?

A variety of communication interfaces are optional, fullysupporting EPC C1G2 ISO 18000-6C/6B protocol, GPIO,RS232 (serial communication) RJ45 (network portcommunication) convenient replacement method,fast replacement speed, can meet the harsh outdoor environment.

What is the operating frequency?

frequency: 865~868MHz/902~928MHz

What is the output power of the reader/writer?

Adjustable, step interval 1db, maximum 30dbm

Do you provide an API?

Only a device SDK is provided.

What is the reading distance of the reader?

We have several types of readers. Each reader has a different reading distance, depending on how far you need to read.

How fast is the reading speed?

It depends on the model; there are models with speeds of 200 tags/second, 700 tags/second, and 800 tags/second.

How far away can it read the tags?

It depends on the model and the tags, but generally it can read them from more than 9 meters away.

What is the tag cache capacity?

The tag cache capacity is 1000 entries.

Is the power consumption high?

Low power consumption Single +9V power supply, optionalPOE power supply.
